SA 420 Gr WPL6 LR / SR Elbow and Low Temperature Carbon Steel WPL6 Pipe Bend Material manufacturer in India
Fittings like elbows are a common choice as devices to bring about change in a piping system. Some pre-determined options for the Carbon Steel WPL6 Elbow are available in angles like 22.5 degrees, 45 degrees or even 90 degrees. Considering the fact that the ASTM A420 WPL6 Elbow is responsible for the change in the direction of flow, one cannot discount the various stressors that occur in the component. One such stressor is the rate of flow, which, in case if too rapid can exert high pressure on the SA 420 WPL6 Elbow. To remedy this issue, most buyers prefer using a harder and denser material like carbon steel. Since carbon steel grades have high hardness and their tensile strength ranges between moderate to high, using an LTCS A420 WPL6 Elbow Fitting for these applications is ideal. Another stress causing factor to be taken into consideration is temperature. Some stainless steel grades are ill-equipped to deal with the load that occurs at low temperature, especially if the viscosity of the media being transported is not constant. The high pressure exerted by a highly viscous media may cause deformation on a highly ductile material like stainless steel. Carbon steel ASTM A420 Gr WPL6 LR 45 Degree Elbow is hard, and thus, is dimensionally stable. Which means that these components are not easily deformed and can retain their shape for several years. Moreover, ASTM A420 WPL6 Buttweld Elbow Pipe Fittings are low carbon alloys, which are well suited for low-temperature service.
ASTM A420 WPL6 Elbow
Carbon Steel WPL6 Elbow
Buttweld WPL6 SR 90 Deg Elbow
LTCS WPL6 LR 45 Degree Elbow
Low Temperature A420 WPL6 Elbow
SA 420 WPL6 90 Deg Elbow
Carbon Steel WPL6 Elbow Equivalent Table
| Pipe | Pipe Tee Fitting | Flanges | Valves | Bolts & Nuts |
|---|---|---|---|---|
| A106 Gr A | A420 Gr WPL6 Elbow | A105 | A216 Gr WCB | A193 Gr B7 A194 Gr 2H |
| A106 Gr B | ASTM A420 gr WPL6 Elbow | A105 | A216 Gr WCB | |
| A106 Gr C | A420 Gr WPL6 Elbow | A105 | A216 Gr WCB |
ASTM A420 WPL6 Elbow
A420 Gr WPL6 SR 90 Deg Elbow Specification
| Specification | ASTM A420 WPL6 Elbow |
| Type | Welded / Seamless |
| Available Types | 3D Elbow, 5D Elbow, 10D Elbow, Equal Cross, Pipe Elbow, BW Tee, Bend, (LR) Long Radius Elbow, Pipe Nipple, Reducers, Caps, Stub End, Pipe / Piggable Bend, (SR) Short Radius Elbow, 2D Elbow |
| Bending Radius | Radius =8D, 2D, 3D, 1D, 6D, 10D, 5D, or Custom |
| Thickness | Sch 160s, Sch 40s, Sch 10s, Sch XXS, Sch 5s, Sch 80s |
| Surface Treatment | Transparent oil, Rust-proof black oil or hot galvanized |
| Size | 1/2" to 24″Inch |
| Dimensions | MSS-SP-43, ASME B16.9, ASME B16.28, ANSI B16.9 |
Contact US for Buttweld A420 Gr WPL6 Short Radius 90 Degree Elbow Instant Delivery In India, Low Carbon A420 WPL6 Buttweld Elbow Pipe Fittings At Lower Prices Compared To USA & UK, Buy Directly From Suppliers Killed Gr WPL6 LR 45 Degree Elbow In Mumbai.
Refer ASTM A420 Gr WPL6 LR 90 Deg Elbow Price List Of In India
| Code | Descripción | Eur/und |
| 1072115 | LR, 90 Deg A420 WPL6 STD 1/2 | 6,95 |
| 1072111 | LR, 90 Deg A420 WPL6 STD 3/4 | 7,86 |
| 1072112 | LR, 90 Deg A420 WPL6 STD 1 | 7,54 |
| 1072113 | LR, 90 Deg A420 WPL6 STD 11/4 | 7,98 |
| 1072114 | LR, 90 Deg A420 WPL6 STD 11/2 | 10,69 |
| 1006990 | LR, 90 Deg A420 WPL6 STD 2 | 9,99 |
Please note this is an approx Price of LTCS ASTM A420 WPL6 45 Deg & 90 Degree Elbow in India. For final Carbon Steel WPL6 Elbow Price List Please Call on +91-90048 48833 or drop an Email to info@highpressurepipefittings.com.
Largest CS A420 Grade WPL6 180 deg Elbow manufacturers in India, We Maintain Good Quality Stock Of Low Temperature A420 WPL6 Long And Short Elbow, Galvanised Grade WPL6 SR Elbow Order Custom Sizes Online.
Low Temperature WPL6 Elbow Chemical Chart
| Grade | C | Mn | P | S | Si | Cr | Mo | Ni | Cu | V | Nb |
| WPB | 0.3 | 0.29-1.06 | 0.05 | 0.058 | 0.1min | 0.4 | 0.15 | 0.4 | 0.4 | 0.08 | 0.02 |
| WPC | 0.35 | 0.29-1.06 | 0.05 | 0.058 | 0.1min | 0.4 | 0.15 | 0.4 | 0.4 | 0.08 | 0.02 |
| WP11 CL1 | 0.05-0.15 | 0.30-0.60 | 0.03 | 0.03 | 0.50-1.00 | 1.00-1.50 | 0.44-0.65 | - | - | - | - |
| WP11 CL2/3 | 0.05-0.20 | 0.30-0.80 | 0.04 | 0.04 | 0.50-1.00 | 1.00-1.50 | 0.44-0.65 | - | - | - | - |
Seamless A420 WPL6 Elbow Mechanical Chart
| Tensile Requirements | WPB | WPC, WP11CL2 | WP11CL1 | WP11CL3 |
| Tensile Strength, min, ksi[MPa] | 60-85 | 70-95 | 60-85 | 75-100 |
| (0.2% offset or 0.5% extension-under-load) | [415-585] | [485-655] | [415-585] | [520-690] |
| Yield Strength, min, ksi[MPa] | 32 | 40 | 30 | 45 |
| [240] | [275] | [205] | [310] |
Chemical Composition Of Carbon Steel A420 WPL6 Elbow Fittings, Mechanical Behavior Of Buttweld / Seamless A420 WPL6 Elbow, Get In Touch For Assistance SA 420 WPL6 Elbow.
Types Of CS A420 Grade WPL6 180 deg Elbow
36 Inch, ASTM A420 WPL6 Welded Fittings 90 Deg Elbow
36 Inch, Welded ASTM A420 WPL6 LR 90 Deg Elbow
12 Inch, ASTM A420 WPL6 Seamless LR 45 Deg Elbow
16 Inch, SCH 80, BW, A420 WPL6 SR 90 Degree Elbows
12 Inch, SCH-STD, A420 WPL6 90 Deg Long Radius Elbow
16 Inch, 36.53mm, ASME B16.9 A420 WPL6 90 Deg Elbow
12 Inch, SCH 14, ASTM A420 WPL6 Butt Weld LR 90 Deg Elbow
24 Inch, SCH STD, ASTM A420 WPL6 45 Deg SR Elbow
16 Inch, SCH 80, A420 WPL6 Long Radius 90D Elbow
8 Inch, SCH STD, 90D, ASME B16.9, ASTM A420 WPL6 LR Elbow
3 Inch, Schedule 80, A420 WPL6 90 Deg Short Radius Elbow
6 Inch, SCH 80, SA420 WPL6 45 Deg Long Radius Elbow
1/2 Inch, SCH 80, ASTM A420 WPL6 Long Radius 90 Deg Elbow
8 Inch, SCH 40, Galvanized, A420 WPL6 90 Deg Long Radius Elbow
6 Inch, SCH 40, A420 WPL6 45 Degree Long Radius Elbow
10 Inch, SCH40, ASTM A420 WPL6 45 Deg Elbow
LTCS A420 WPL6 Elbow Fitting Dimensional Format, ASTM A420 WPL6 Elbow Schedule Chart, SA 420 WPL6 90 Deg Elbow For Fastest Delivery To Our Customers In India.
SA 420 WPL6 Elbow Dimension Table
| Normal Size Of Pipe | O.D. | I.D. | Wall Thick. Chart |
Center To End |
Pipe Sch |
Weight In Pound |
| 1 | 1.32 | 1.05 | 0.133 | 1 | 40 | 0.25 |
| 1 1/4 | 1.66 | 1.38 | 0.14 | 1.25 | 40 | 0.39 |
| 1 1/2 | 1.9 | 1.61 | 0.145 | 1.5 | 40 | 0.53 |
| 2 | 2.38 | 2.07 | 0.154 | 2 | 40 | 0.97 |
| 2 1/2 | 2.88 | 2.47 | 0.203 | 2.5 | 40 | 2 |
| 3 | 3.5 | 3.07 | 0.216 | 3 | 40 | 3 |
| 3 1/2 | 4 | 3.55 | 0.226 | 3.5 | 40 | 4.3 |
| 4 | 4.5 | 4.03 | 0.237 | 4 | 40 | 6.1 |
| 5 | 5.56 | 5.05 | 0.258 | 5 | 40 | 9.7 |
| 6 | 6.63 | 6.07 | 0.28 | 6 | 40 | 16.7 |
| 8 | 8.63 | 7.98 | 0.322 | 8 | 40 | 32.4 |
| 10 | 10.75 | 10.02 | 0.365 | 10 | 40 | 56.3 |
| 12 | 12.75 | 12 | 0.375 | 12 | * | 79.4 |
| 14 | 14 | 13.25 | 0.375 | 14 | 30 | 104 |
| 16 | 16 | 15.25 | 0.375 | 16 | 30 | 129 |
| 18 | 18 | 17.25 | 0.375 | 18 | * | 163 |
| 20 | 20 | 19.25 | 0.375 | 20 | 20 | 210 |
| 24 | 24 | 23.25 | 0.375 | 24 | 20 | 297 |
| 30 | 30 | 29.25 | 0.375 | 30 | * | 480 |
| 36 | 36 | 35.25 | 0.375 | 36 | * | 692 |
| 42 | 42 | 41.25 | 0.375 | 42 | * | 967 |
| 48 | 48 | 47.25 | 0.375 | 48 | * | 1,340 |
LTCS A420 WPL6 Elbow Schedule Chart
| Sch | Size of Pipe | Weight In Kilogram |
|---|---|---|
| 1 1/4" | 1 1/4" | 0.5 |
| 1 1/2" | 1 1/2" | 0.8 |
| 2" | 2" | 1.4 |
| 2 1/2" | 2 1/2" | 2.7 |
| 3" | 3" | 4.2 |
| 8" | 8" | 20.9 |
| 4" | 4" | 7.9 |
| 1/2" | 1/2" | 0.1 |
| 3/4" | 3/4" | 0.1 |
| 2 1/2" | 2 1/2" | 1.3 |
| 1" | 1" | 0.2 |
| 1 1/4" | 1 1/4" | 0.3 |
| 1 1/2" | 1 1/2" | 0.4 |
| 2" | 2" | 0.7 |
| 4" | 4" | 4 |
| 10" | 10" | 37 |
| 12" | 12" | 54 |
| 5" | 5" | 3.3 |
| 1" | 1" | 0.1 |
| 3" | 3" | 2.1 |
| 1 1/4" | 1 1/4" | 0.2 |
| 2 1/2" | 2 1/2" | 0.7 |
| 1 1/2" | 1 1/2" | 0.2 |
| 2" | 2" | 0.4 |
| 6" | 6" | 10.4 |
| 4" | 4" | 2 |
| 6" | 6" | 5.1 |
| 8" | 8" | 10.3 |
| 5" | 5" | 6.7 |
| 3" | 3" | 1.1 |
| 10" | 10" | 18.3 |
